Sliding Window
We specialise in high-quality aluminium sliding windows that seamlessly blend style, functionality and durability. Designed to maximise natural light and ventilation while maintaining a sleek, contemporary appearance.
Stylish, highly energy-efficient, secure and built to last.
- ●Sliding
- ●80mm (CWD80) · 100mm (CWD100)
- ●Double-Glazed Std.
- ●AS/NZS 2208
- ●CWD80 · CWD100
The difference is in the detail.
Double-Glazed as Standard
A 5+12A+5 insulating glass unit dampens noise and steadies indoor temperature — included in every unit, not an upgrade.
Wide Aperture, Sleek Sightline
Up to 50% of the opening clears for ventilation, with thin 100mm frames keeping the view open.
Smooth Glide, Quiet Close
Premium roller tracks and continuous seals — opens with one hand, closes flush against EPDM gaskets.
Built to standard.
- Model
- CWD80 · CWD100
- Opening Style
- Sliding
- Profile Thickness
- 2.0mm
- Profile Width
- 80mm (CWD80) · 100mm (CWD100)
- Glass Options
- 5mm + 12A + 5mm / 6mm + 12A + 6mm
- Glass Standard
- AS/NZS 2208
- Extrusion Profile
- 6063-T5 Aluminium (CWD100: thermally broken)
- Standard Hardware
- Window pulley hardware — SIEGENIA (DE) / Doric (AU)
Glass Types
- Tempered
- Toughened
- Coated
- LOW-E
Glass Colours
- Clear
- Grey
- Blue
- Green
- Custom
Profile Colours
- Matt Black
- Monument
- White
Flyscreen Options
- Aluminium
- Fiberglass
- Stainless Steel
- Waterproof
- Heat / Cold resistance
- Soundproof
- Wind resistance
- Airtight
- Safe
Residential · Commercial · Hospitality · Healthcare · School · Municipal
Custom Sliding Windows Installation
Double or triple glazing, acoustic glass for noise reduction, thermal break frames for insulation, security locks and flyscreens.
Professional installers ensure compliance with Australian Standards and local Canberra building codes.
Repairs & Replacements
Track and roller repairs, glass replacement, weatherproofing, hardware upgrades.
For specifiers & builders.
Cross-section and installation detail sheets for both frame series. PDF — open in a new tab.
